Dahua XVR5116HS-4KL 16 Channel Penta-brid 4K Compact 1U Digita
Product Specifications
| Feature | Description |
|---|---|
| Max. Channel | 16 inputs |
| Resolution | 1080P |
| Internal HDD | (Up to 8 TB) |
| Warranty | 12 Month |
For price call us.
(973) 732 - 1343
Product Description:
| System | ||
| Main Processor | Embedded Processor | |
| Operating System | Embedded LINUX | |
| Audio and Video | ||
| IP Camera Input | 16+8 Channel, each channel up to 8MP | |
| Two-Way Talk | Reuse audio in/Out, RCA | |
| Display | ||
| Interface | 1 HDMI, 1 VGA | |
| Resolution | HDMI:3840×2160, 2560×1440, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720 |
|
| Multi-Screen Display | When IP extension mode not enabled: 16CH: 1/4/8/9/16 When IP extension mode enabled: 16CH: 1/4/8/9/16/25 |
|
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
| Recording | ||
| Compression | H.265+/H.265/H.264+/H.264 | |
| Resolution | 4K, 6MP, 5MP, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, CIF | |
| Record Rate | Main stream: 4K(1~7fps); 6MP(1~10fps); 5MP(1~12fps); 4MP/3MP(1~15fps); 4M-/ 1080P/ 720P/ 960H/ D1/ CIF(1~25/30fps) Sub stream:960H(1~15fps); D1/ CIF(1~25/ 30fps) |
|
| Bit Rate | 32Kbps ~ 6144Kbps Per Channel | |
| Record Mode | Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop | |
| Record Interval | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec | |
| Video Detection And Alarm | ||
| Trigger Event | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips | |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis | |
| Playback And Backup | ||
| Sync Playback | 16CH: 1/4/9/16 | |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) | |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom | |
| Backup Mode | USB Device/Network | |
| Third Party Support | ||
| Third Party Support | Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more | |
| Network | ||
| Interface | 1 RJ-45 Port (1000M) | |
| Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.) | |
| Maximum User Access | 128 users | |
| Smart Phone | iPhone, iPad, Android | |
| Interoperability | ONVIF 16.12, CGI Conformant | |
| Storage | ||
| Internal HDD | 1 SATA Port, up to 10TB capacity | |
| Auxiliary Interface | ||
| USB | 2 USB Ports (1 USB 2.0,1 USB 3.0) | |
| RS485 | 1 Port, for PTZ Control | |
| Power | ||
| Power Supply | 16CH:DC12V/3A | |
| Power Consumption | 16CH:<20W | |
| Component Environment | ||
| Operational Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 10% ~ 90% RH | |
| Storage Conditions | -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH | |
| Construction | ||
| Dimensions | Mini 1U, 325mm×255mm×55mm (12.8" x 10" x 2.2") | |
| Net Weight | 1.3kg | |
| Gross Weight | 2.0kg | |
